| 型 式 | 容 量 | 内 径 D |
胴 長 L1 |
全 長 L2 参考寸法 |
鉄板板厚 T |
|---|---|---|---|---|---|
| SFO-1.9 | 1,900 | 950 | 2,700 | 3,120 | 6.0 |
| SFO-3 | 3,000 | 1,200 | 2,700 | 3,218 | 6.0 |
| SFO-4 | 4,000 | 1,300 | 3,000 | 3,556 | 6.0 |
| SFO-5 | 5,000 | 1,300 | 3,800 | 4,356 | 6.0 |
| SFO-6 | 6,000 | 1,400 | 4,000 | 4,595 | 6.0 |
| SFO-7 | 7,000 | 1,500 | 4,000 | 4,634 | 6.0 |
| SFO-8 | 8,000 | 1,500 | 4,600 | 5,234 | 6.0 |
| SFO-10 | 10,000 | 1,600 | 5,200 | 5,893 | 9.0 |
| SFO-12 | 12,000 | 1,800 | 4,800 | 5,570 | 9.0 |
| SFO-13 | 13,000 | 1,800 | 5,200 | 5,970 | 9.0 |
| SFO-15 | 15,000 | 1,800 | 6,000 | 6,770 | 9.0 |
| SFO-18 | 18,000 | 1,900 | 6,500 | 7,310 | 9.0 |
| SFO-20 | 20,000 | 1,900 | 7,200 | 8,010 | 9.0 |
| SFO-25 | 25,000 | 2,000 | 8,200 | 9,010 | 9.0 |
| SFO-30 | 30,000 | 2,200 | 8,200 | 9,126 | 9.0 |
| SFO-40 | 40,000 | 2,400 | 9,100 | 10,104 | 9.0 |
| SFO-50 | 50,000 | 2,800 | 8,400 | 9,558 | 9.0 |
